M5 Pro vs M5 Max: MacBook Pro With PROLED XDR Display

The short version

• M5 Pro offers up to 64GB unified memory; M5 Max adds more GPU cores, higher memory bandwidth, up to 128GB memory, and another supported external display.
• Both sizes offer M5 Pro and M5 Max, but the M5 Pro with a 15-core CPU and 16-core GPU is exclusive to the 14-inch model.
• The 32-core GPU M5 Max offers 36GB unified memory, so choosing Max does not automatically mean getting more memory than every Pro configuration.

On the MacBook Pro with PROLED XDR Display, the specific GPU variant determines your memory and SSD choices, while the laptop’s size and chip also affect battery ratings, weight, and the included power adapter.

M5 Pro and M5 Max chip options by size

Apple sells four chip options across the two sizes: two M5 Pro variants and two M5 Max variants.

CPU, GPU, and size combinations

Chip	CPU	GPU	Available sizes
M5 Pro	15-core CPU	16-core GPU	14-inch
M5 Pro	18-core CPU	20-core GPU	14-inch and 16-inch
M5 Max	18-core CPU	32-core GPU	14-inch and 16-inch
M5 Max	18-core CPU	40-core GPU	14-inch and 16-inch

The Pro or Max name is only part of the configuration: memory and storage selections attach to the particular GPU variant.

Compare MacBook Pro configurations by size and chip

CPU core count alone does not separate the 18-core M5 Pro from either M5 Max option, so GPU cores, memory, and display support decide between them.

M5 Pro with a 16-core GPU

This configuration’s CPU consists of 5 super cores and 10 performance cores. Its unified memory bandwidth is 307GB/s.

The memory choices are 24GB or 48GB unified memory, making 48GB this variant’s ceiling. SSD selections are 1TB, 2TB, or 4TB.

Memory choices for the 20-core GPU M5 Pro

This option uses 6 super cores and 12 performance cores, with 307GB/s memory bandwidth.

You can choose 24GB, 48GB, or 64GB unified memory. The additional 64GB selection extends the M5 Pro family’s memory ceiling, while SSD choices remain 1TB, 2TB, or 4TB.

M5 Max with a 32-core GPU

This M5 Max variant combines 6 super cores and 12 performance cores with 460GB/s memory bandwidth.

Its memory selection is 36GB unified memory. Storage choices are 2TB, 4TB, 8TB, or 16TB SSD.

The 40-core GPU M5 Max configuration

This variant has 6 super cores and 12 performance cores and 614GB/s memory bandwidth.

Memory selections are 48GB, 64GB, or 128GB unified memory. Access to 128GB specifically requires this M5 Max variant; its SSD choices are 2TB, 4TB, 8TB, or 16TB.

Neural Engine features and media hardware

Every chip option includes Neural Accelerators, hardware-accelerated ray tracing, and a 16-core Neural Engine.

Both chip families support hardware-accelerated H.264, HEVC, ProRes, and ProRes RAW, plus AV1 decoding. The media-engine hardware differs by family, with the same engine configuration applying to both GPU variants within each family.

Media engines by chip family

Media Engine	M5 Pro	M5 Max
Video decoding	Video decode engine	Video decode engine
Video encoding	Video encode engine	Two video encode engines
ProRes encoding and decoding	ProRes encode and decode engine	Two ProRes encode and decode engines

External display counts, resolutions, and refresh rates

Both families support simultaneous use of the built-in display at full native resolution alongside external monitors. Their Thunderbolt 5 (USB-C) ports support native DisplayPort 2.1 speeds.

External displays can connect through any combination of Thunderbolt and HDMI ports. Match your monitor arrangement by its complete combination of display count, resolution, and refresh rate; the higher-resolution arrangements are alternatives to the maximum-count arrangements.

Supported external monitor arrangements

Display arrangement	M5 Pro	M5 Max
Maximum-count arrangement	Three displays, each up to 6K at 60Hz or 4K at 165Hz	Four displays, each up to 6K at 60Hz or 4K at 165Hz
Alternative higher-resolution arrangement	One display up to 8K at 60Hz, 5K at 120Hz, or 4K at 240Hz, plus a second display up to 5K at 120Hz or 4K at 200Hz	Two displays, each up to 8K at 60Hz, 5K at 120Hz, or 4K at 240Hz
Through a single Thunderbolt port	Up to three external displays	Up to four external displays

Battery ratings and carrying weight

Apple’s battery ratings cover video streaming and wireless web browsing.

Battery and weight by model

Size and chip	Video streaming	Wireless web	Battery	Weight
14-inch M5 Pro	Up to 22 hours	Up to 14 hours	72.6-watt-hour lithium-polymer	3.0 pounds (1.38 kg)
14-inch M5 Max	Up to 20 hours	Up to 13 hours	72.6-watt-hour lithium-polymer	3.1 pounds (1.40 kg)
16-inch M5 Pro	Up to 24 hours	Up to 17 hours	100-watt-hour lithium-polymer	4.0 pounds (1.82 kg)
16-inch M5 Max	Up to 22 hours	Up to 16 hours	100-watt-hour lithium-polymer	4.1 pounds (1.84 kg)

Apple conducted testing in September 2026 using preproduction systems. The 14-inch M5 Pro test configuration had an 18-core CPU, 20-core GPU, 24GB unified memory, and 4TB SSD. The 14-inch M5 Max test configuration had an 18-core CPU, 32-core GPU, 36GB unified memory, and 4TB SSD.

The 16-inch M5 Pro test configuration used an 18-core CPU, 20-core GPU, 48GB unified memory, and 2TB SSD. The 16-inch M5 Max test configuration used an 18-core CPU, 40-core GPU, 48GB unified memory, and 8TB SSD.

Wireless web testing involved browsing 25 popular websites over Wi-Fi. Streaming testing used 1080p content in Safari over Wi-Fi. Display brightness was set to 8 clicks from the bottom, and the keyboard backlight was off.

Battery life varies with use, configuration, and environmental factors. Weight varies with configuration and manufacturing process.

Included adapters and charging requirements

Both sizes support charging through a USB-C power adapter or another USB PD power source. The minimum recommended charging wattage is 70W for the 14-inch model and 94W for the 16-inch model.

[[component: dont-miss]]
KIND: dont_miss
VALUE: 96W or higher
RULE: The 14-inch model is fast-charge capable with a 96W or higher USB PD power source
WHY: The 70W adapter that comes with the 15-core M5 Pro configuration is below this threshold
[[/component]]

Power adapters supplied with each configuration

Configuration	Included power adapter
14-inch M5 Pro with 15-core CPU	70W Power Adapter
14-inch M5 Pro with 18-core CPU, or either M5 Max variant	96W Power Adapter
Every listed 16-inch configuration	140W USB-C Power Adapter

The 16-inch model is fast-charge capable with a 140W or higher USB PD power source.

Choose around your workload’s resource requirements

Start with memory, then displays. M5 Pro covers memory selections up to 64GB and up to three external displays. M5 Max is the family for 128GB memory or a fourth external display, and its memory choices depend on the GPU variant: 36GB with the 32-core GPU, or 48GB, 64GB, or 128GB with the 40-core GPU.

For graphics work, GPU cores rise from 16 on the entry M5 Pro to 40 on the top M5 Max. Memory bandwidth is 307GB/s on both M5 Pro options, 460GB/s on the 32-core M5 Max, and 614GB/s on the 40-core M5 Max.

MacBook Pro with PROLED XDR Display release date

Pre-orders for the MacBook Pro with PROLED XDR Display opened on October 28, and it begins arriving to customers starting Friday, November 6. Delivery options at checkout depend on your location and product availability, and some customized selections may affect delivery estimates and options.

FAQs

Does the listed SSD capacity equal usable formatted capacity?

No, actual formatted SSD capacity is less than the listed capacity. Storage units use decimal measurements: 1GB equals 1 billion bytes, and 1TB equals 1 trillion bytes.

Which charging cable comes with either MacBook Pro size?

Both sizes include a USB-C to MagSafe 3 Cable. The supplied cable is 2 m long.

Does every MacBook Pro configuration include a polishing cloth?

A polishing cloth is included only when you select the nano-texture glass option.

---
