XPERIA SP RECOVERY MODE
A recovery is a separate bootable partition on your Android device that you can use to install system updates and repair (factory reset) your device. A lot more can be done using a custom recovery, but the stock recovery that comes pre-installed on Android devices is limited to these features only. And FYI, these features are integrated into the Android OS as well — when you choose to factory reset your device from device settings or install an OTA update, your device reboots and boots into the stock recovery to finish the job.
The recovery installed on your device may not be touch-friendly. You’ll have to use the Power and Volume buttons available on your device to select and navigate between options in the recovery.
There are multiple methods to boot your Xperia SP in recovery mode. The most handy (and hardware coded) method is about pressing a particular hardware button a couple of times while booting up your Xperia SP. Others are software based, let’s have a look at them below.
Sony Xperia devices don’t ship with a pre-installed recovery. So unless you’ve installed a custom recovery like CWM or TWRP on your device, you won’t be able to boot into recovery mode.
This method is a fail-proof method that’ll always work for you, unless you’ve broken one of hardware keys. In such a case you’d be left with only the other two methods discussed on this page.
- Switch off your Xperia SP first
- Switch it back on and the time when you see your phone’s LED notification light turn Pink! (or changes to any other color) — start pressing either the Volume UP or Volume Down key a couple of times to make your phone boot into recovery mode
- Once you’re in recovery mode. Use Volume buttons to navigate Up and Down between options and Power button to select an option in recovery.
2) Boot into Xperia SP Recovery Mode Using ADB
ADB stands for Android Debug Bridge, a tool used to send terminal commands to a Android device via a PC command line. ADB requires a bit of setup, but it gets the job done with much lesser effort than hardware buttons, so pretty useful in cases when you’ve to boot into recovery mode frequently. Also, if (for some reason) your hardware buttons aren’t working than this is a very good alternative to boot into recovery mode.
First off, DOWNLOAD ADB FILES →
And make sure you’ve proper drivers installed for your device.
- Extract the file (ADB files.zip) you downloaded from the link above to a separate folder on your computer
- Prepare your phone
- Enable developer options: Go to your phone’s Settings » select About phone » Scroll to the bottom and tap on “Build number” seven times to enable developer options
- Enable USB Debugging: Open phone’s Settings » select Developer options » Tick the “USB debugging” checkbox (under Debugging section)
- Connect your phone to PC with a USB cable and if/when a pop-up screen shows up on Phone asking you to ‘Allow USB debugging?‘ for the computer, make sure you tick the checkbox and tap OK
- Open the folder where you extracted the files and double-click/run the ‘Boot into Recovery Mode.bat‘ file to reboot your device into recovery mode
└ If the script shows any error than that means either your device is not connected or you don’t have proper driver for your device installed on your PC.
FYI, the ‘Boot into Recovery Mode.bat‘ script file that we used above to boot your device into recovery mode only uses one line of command:
adb reboot recovery
If you already have ADB setup on your computer and you know how to use it, then you may just use the command given above to boot into recovery mode.
3) Boot into Xperia SP Recovery Mode Using Quick Boot (Reboot) APP
Yes! There’s an app for rebooting your phone into recovery mode, and it’s the most easier of the methods we discussed above. But it won’t work unless you’ve root access on your device, and since not everyone roos their device, we’ve put this as the last method here.
ROOT ACCESS REQUIRED
- Install the Quick Boot (Reboot) app from Play Store on your Xperia SP | Play store link →
- Open the app and grant Root Access
- Select ‘Recovery‘ from the list of options and it’ll boot your device into recovery mode
Let us know in the comments below if you need any other help, we’d be happy to help.
